YD-136 Epoxy Resin

YD-136 Epoxy Resin is a high-performance bisphenol-A-based epoxy resin from the YD series by Wuxi Yada Chemical. It offers excellent adhesion, chemical resistance, and mechanical strength, widely used in composites, coatings, and electronic encapsulation. Low viscosity, good compatibility with hardeners, and superior electrical insulation make it ideal for demanding industrial applications.
  • yd 136 epoxy resin_6aca3851
  • yd 136 epoxy resin_6aca3851

Features Of YD-136 Epoxy Resin

  1. High purity bisphenol-A based liquid epoxy resin with consistent molecular weight distribution.

  2. Excellent compatibility with standard amine and anhydride curing agents for broad formulation flexibility.

  3. Low viscosity (12,000–14,000 cP at 25°C) enabling easy processing, mixing, and impregnation.

  4. Superior electrical insulation properties and low dielectric loss at elevated frequencies.

  5. Good thermal stability with glass transition temperature (Tg) of cured system up to 125°C.

Typical Applications Of YD-136 Epoxy Resin

  1. Electrical encapsulation and potting compounds for transformers, sensors, and power modules.

  2. High-voltage insulating varnishes and coil impregnation resins in motor and generator manufacturing.

  3. Structural adhesives requiring thermal resistance and dimensional stability under cyclic loading.

  4. Composite matrix resin for glass fiber-reinforced laminates in aerospace and industrial tooling.

  5. UV-curable hybrid formulations when combined with acrylate co-monomers and photoinitiators.

Specifications Of YD-136 Epoxy Resin

Chemical TypeBisphenol-A diglycidyl ether (DGEBA)
Product FormClear, pale yellow liquid
AppearanceTransparent, slightly viscous liquid
Epoxy Equivalent Weight (EEW)188–194 g/eq
Viscosity (25°C)12,000–14,000 cP
Epoxide Content17.5–18.2 wt%
Volatile Matter (max)0.3 wt%
Chloride Content (max)800 ppm
