DOW SILASTIC 3-8186 is a two-component silicone elastomer crafted for precise sealing uses. It has a 1:1 mixing ratio (Part A/B density: 1.12/1.22 g/cm³) and dynamic viscosity of 135,000/125,000 cps. Under low-temperature curing (75°C/10min), it turns into elastic foam, reaching compressive strength of 0.032-0.33 MPa (25-75% deflection) and tensile strength of 0.18 MPa (140% elongation). Its low sealing force (<26 psi) design lessens assembly stress, making it perfect for automotive and lighting waterproofing through robotic dispensing systems.
Low-Temp Curing: Fully cures at 75°C in 10 minutes, boosting energy efficiency effectively.
Thixotropic Flow Property: With 200,000 cps viscosity, it avoids sagging when applied on vertical surfaces.
Sealing Force Management: The low-density foam (0.225 g/cm³) reduces component deformation to a minimum.
Thermal Stability: Functions normally from -40°C to 150°C and meets automotive thermal cycling test standards.
Accurate Mixing: The 1:1 weight ratio allows it to work with automated equipment smoothly.
Automotive: Seals headlights and provides waterproofing for ECU housings (meeting IP67 standards).
Lighting: Encapsulates LED modules and enhances moisture resistance of outdoor fixtures.
Electronics: Packages sensors and enables waterproofing for consumer electronic devices.
Industrial Equipment: Makes valve gaskets and seals pipeline joints.
Type | Two-component silicone foam |
Density (Part A/B) | 1.12/1.22 g/cm³ |
Viscosity (Part A/B) | 135,000/125,000 cps |
Mix Ratio | 1:1 (by weight) |
Curing Condition | 75°C/10 minutes |
Compressive Strength (25% deflection) | 0.032 MPa |
Tensile Strength | 0.18 MPa (ASTM D412) |
Elongation at Break | 140% |
Operating Temperature | -40°C to 150°C |
Packaging | 18.1 kg/pail (Part A/B separately) |
