Two-part, platinum-catalyzed addition-cure silicone rubber system offering excellent dimensional stability and low shrinkage.
High transparency and exceptional clarity after curing, suitable for optical and aesthetic applications.
Outstanding thermal resistance with continuous service capability up to 180 °C and short-term exposure to 200 °C.
Low compression set and superior elasticity retention under repeated stress or elevated temperature conditions.
Meets UL 94 V-0 flammability rating when formulated with appropriate fillers and cured per specification.
LED encapsulation and optical lens molding for high-brightness lighting systems.
Medical device components requiring biocompatibility (ISO 10993-compliant when fully cured).
Automotive sensors and electronic protection gels exposed to under-hood thermal cycling.
Consumer electronics potting and sealing where optical clarity and long-term reliability are critical.
Industrial automation parts demanding chemical resistance to oils, solvents, and humidity.
| Chemical Type | Platinum-catalyzed addition-cure silicone elastomer |
| Product Form | Two-component liquid (Part A: base polymer + filler; Part B: crosslinker + catalyst) |
| Appearance (Uncured) | Part A: translucent viscous liquid; Part B: colorless to pale yellow liquid |
| Mixing Ratio (A:B by weight) | 100 : 1.0 |
| Cure Conditions (Standard) | 150 °C for 5 minutes or 100 °C for 60 minutes |
| Hardness (Shore A, ASTM D2240) | 40 ± 2 |
| Tensile Strength (ASTM D412) | ≥ 7.0 MPa |
| Elongation at Break (ASTM D412) | ≥ 250 % |
