Ticona TPU-GF50-01-US TPU Elastomer

Features Of Ticona TPU-GF50-01-US TPU Elastomer

1. High-performance thermoplastic polyurethane elastomer with 50% glass fiber reinforcement for exceptional stiffness and dimensional stability.

2. Excellent melt flow characteristics enabling efficient processing via injection molding and extrusion.

3. Outstanding mechanical strength, including high tensile modulus and impact resistance at elevated temperatures.

4. Good chemical resistance to oils, greases, and many industrial solvents under typical service conditions.

5. UL94 HB flame retardancy rating without halogenated additives, supporting safer material handling and end-use compliance.

Typical Applications Of Ticona TPU-GF50-01-US TPU Elastomer

1. Automotive interior trim components requiring rigidity, surface quality, and thermal stability.

2. Industrial power transmission parts such as pulleys, gear housings, and motor mounts.

3. Heavy-duty connectors and structural housings in electrical and electronic equipment.

4. Demanding fluid-handling components including pump bodies, valve manifolds, and pressure-resistant fittings.

5. Material handling systems featuring wear-resistant conveyor guides, rollers, and mounting brackets.

Specifications Of Ticona TPU-GF50-01-US TPU Elastomer

Ticona TPU-GF50-01-US TPU Elastomer – Frequently Asked Questions (FAQ)

Q1: What is the primary functional advantage of Ticona TPU-GF50-01-US compared to standard TPU grades?

A: Ticona TPU-GF50-01-US is a glass-fiber reinforced thermoplastic polyurethane elastomer engineered to deliver significantly enhanced stiffness, dimensional stability under load, and heat resistance—while retaining good impact toughness and processability in standard injection molding equipment.

Q2: Is this grade suitable for injection molding of thin-walled or highly detailed parts?

A: Yes, it is formulated for reliable flow into complex geometries; however, due to its glass-fiber reinforcement, mold design should account for fiber orientation effects—especially in areas with abrupt wall thickness transitions or tight radii—to minimize warpage and ensure consistent mechanical performance.

Q3: How does moisture sensitivity compare to non-reinforced TPUs, and what drying recommendations apply?

A: Like most TPUs, Ticona TPU-GF50-01-US is hygroscopic and requires thorough drying prior to processing. Due to the presence of glass fibers, extended drying times may be needed to ensure uniform moisture removal—typically 3–4 hours at 80–90 °C with dew point ≤ −30 °C is recommended, but actual conditions should be validated per drying equipment and ambient humidity.

Q4: Can this material be overmolded onto other thermoplastics such as ABS or PC?

A: Successful two-shot or multi-material overmolding is possible with careful thermal and rheological matching—particularly regarding melt temperature windows and interfacial adhesion. Adhesion performance depends heavily on substrate surface energy, mold temperature control, and gate design; pilot trials are strongly advised to confirm bond integrity and long-term durability.
