Zero ozone depletion potential (ODP = 0) and low global warming potential (GWP < 15).
Non-flammable under standard atmospheric conditions (ASTM D3278 pass at 60°C).
Exceptional thermal and chemical stability across wide pH and temperature ranges.
Low surface tension and high volatility enable rapid, residue-free drying.
Compatible with most common elastomers and engineering plastics used in precision cleaning systems.
Final rinse solvent for high-precision electronics and semiconductor components.
Carrier fluid for flux residue removal in vapor phase degreasing equipment.
Low-residue cleaning agent for medical device assembly and sterilization prep.
Formulation component in non-aqueous, no-rinse optical lens cleaning solutions.
Environmental test chamber purge medium requiring inert, non-condensing properties.
| Chemical Type | Hydrofluoroether (HFE), branched C5 structure |
| Product Form | Clear, colorless liquid |
| Appearance | Transparent, odorless to mild ether-like odor |
| Boiling Point (1 atm) | ~49–51°C |
| Melting Point | < –100°C |
| Density (20°C) | 1.28–1.30 g/cm³ |
| Refractive Index (20°C) | 1.270–1.275 |
| Regulatory Compliance | REACH registered; EPA SNAP-listed for industrial cleaning; non-Prop 65 listed |
| Common Compatible Systems | Suitability |
| Vapor degreasing equipment (e.g., Precision Cleaning Systems Model VD-3000) | Highly Recommended – Optimized for closed-loop recovery and minimal carryover |
| Ultrasonic cleaning systems with HFE-compatible tanks (PP, PVDF, or 316 stainless steel) | Recommended – Requires temperature control ≤ 45°C to maintain stability |
| Automated spray-in-air precision cleaning lines | Suitable – Effective with standard PTFE and Viton® seals; verify nozzle material compatibility |
| Batch immersion cleaning tanks with filtration and distillation | Highly Recommended – High recovery yield (>92%) and low degradation over 500+ cycles |
Q1: What is the CAS Registry Number for JD7076 Hydrofluoroether?
A: The CAS Number is 132182-72-8, corresponding to 1,1,1,2,2,3,4,5,5,5-decafluoro-3-methoxy-4-(trifluoromethyl)pentane.
Q2: Is JD7076 suitable as a direct replacement for HCFC-225 or CFC-113 in existing equipment?
A: Yes — JD7076 exhibits similar volatility, solvency, and material compatibility profiles; however, minor adjustments to boil-off temperature and condenser settings are recommended during retrofitting.
Q3: Does JD7076 migrate into or extract plasticizers from polymeric components?
A: No significant migration or extraction has been observed in validated testing with PVC, TPE, and silicone elastomers at exposure times ≤ 10 min and temperatures ≤ 40°C.
Q4: Are there restrictions on transportation or storage per IATA/IMDG regulations?
A: JD7076 is classified as Non-Hazardous for transport (UN 3082 not applicable); it is not subject to IATA/IMDG Class 3 flammability requirements and may be shipped as “Not Restricted” when packaged in approved containers.
